X-Ray Baggage Scanner
Model: Trust Safety Solutions 8065
(Tunnel Size:-800x650mm)
Features:
• Linux Operation System
• ARM CPU
• Digital signal and processor
• Continuous hard work for 10000 hours
• Energy saving design
• High penetration
• Good quality images
• One Key Turn Of
Product Size - 2848* 1095 * 1536mm (L × W × H) (L × W × H)
Tunnel Size - 807.5* 653mm (width × height)
Wire Resolution - Typical AWG36
Penetration Resolution -Typical AWG24
Spatial Resolution - Vertical 2.0mm; Horizontal 2.0 mm
Penetration - Typical 30mm
X raydose per each inspection - ≤ 2.5 μGy
Boundary Leakage -≤ 0.5 (μGy/h)
S/N Ratio - < 60dB
Conveyor Speed - 0.2(m/s)
Conveyor Max Load - 200(kgs)
Power Consumption - 1.0 KW
Leakage current - ≤ 5.0mA
Film Safety - Guarantee ASA/ISO 1600 Film
Operating Environment
Operation temperature/Humidity - 5℃-40℃ / 0%-90%
Storage Temperature/Humidity - -20℃ - 60℃ / 10%-90%
Operation Power - 220VAC(±10%-15%) 50±3Hz
Monitor - 17" L E D screen, resolution: 1280*1024 pixels
Operation console - Double Screen Console
Computer - Hard drive: 500G, Storage: 1G
Compliance:
ISO19001 ; ISO14001 ; ISO27001
• CE , ROHS , FCC , REACH , USA , FDA
• Health Inspection Report
• Computer Software Copyright Registration Certificate
• Software Product Registration Certificate
• Radiation Safety Certificate from Ministry of Public Security
Warranty : 1 Year
