RFID KTI Digital Key Management System with 7 Inch Screen 16 Face
RFID KTI Digital Key Management System with 7 Inch Screen 16 Face

RFID KTI Digital Key Management System with 7 Inch Screen 16 Face

KTI04004003KDMS_16_Face

RFID-Based Electronic Key Management System with 7" Screen Size
KeyGuard with 7” touch screen+Camera + embedded/external server
7” Touch Screen, graphical UI
KeyGuard-7T with 7” Touch screen
1. A colour Graphic 7” touch screen LCD provides user interface.
2. A cabinet Holds Conventional Keys securely
3. Key attached to RFID tag with locking arrangement
4. All keys are uniquely identified and individually locked.
5. Keys can be placed in any slots. Optionally Keys can be assign to
fixed slots
6. User identification using ID cards, fingerprint OR PIN entry . [IRIS /
Face optional]
7. Keys are issued to authorised users only.
8. Blinking multi-colour LED indicates Key being released.
9. Built-in camera to record snapshots of operations
10. Logs time of issue and time of return accurately
11. Works in standalone mode and also in networked mode
Features
12. User friendly GUI
13. Supports Indian languages
14. On screen key search facility
15. Versatile time/date based Key restrictions
16. Versatile dual authentication for keys
17. Onscreen Key transaction report
18. Release-all-Keys mode for
administrator.
19. Audio: Voice prompts [ English / Indian]
20. Senses Key tamper / cabinet tamper
21. Alarm contact outputs for external interface
22. Digital inputs for external interface
23. Modular design: each holding 16 Keys per Key module
24. Upto 64 Key modules in one cabinet (1024 Keys)
25. The design is field expandable (16..1024 Keys).
26. Secure mechanical override to release keys in case of emergency
Specifications
27. ID Card reading & processing time < 150ms.
28. Typical Key dispensing time ~= 2-3Sec.
29. Power supply: 160-230V ac/50Hz.
30. Battery backup power supply for 2-hours
31. Enclosure: 18 SWG, MS powder coated cabinet, with SS front plate.
32. Environment: Temperature 0-55 Deg. C, RH 0-95%
Web GUI
33. OS independent, web browser based GUI.
34. Multiple Operators to manage cabinets
35. Graphical User Friendly Interface.
36. Assigning and/or De-assigning Keys and Groups to multiple Users. With
audit trail.
37. Creating of multiple time constraints / shifts
38. Assigning of shifts/time restriction to keys or users.
39. Flexible Options of dual authentication of each key.
40. Graphical display of Keys present in the Cabinet.
41. Real-Time transactions are displayed as and when they occur.
42. flexible Email Notifications configuration.
43. Remote release of keys from cabinet, by
authorised operator.
44. Accurate Report Generation based upon
various kinds of Key Transactions taken
place.
45. Audit Trail of all operations performed by
the Operator.
46. Multi User login with Captcha Code
Security
47. Assigning and/or De-assigning Access
Rights to the Operators.
48. secure APIs for user / Key / transactions
for remote host.
49. Compatible with Chrome & Mozilla.
50. TLS protocol for data security
