Sliding Door
Max Clear Opening 2000 mm Width X 2400 mm Height Accessories Included: - • Motion Sensor 2 No
• Safety Sensor (One Set)
• 12 mm Thick Glass Panel Holding Bracket 4 No.
• Moving Frame Panel Guiding Floor Bracket 2 No
• Moving Frame- Less Guiding Floor Bracket 2 No Silent Features: -
• Rail & Cover: - 4.2 Meter Rail & Cover – Maximum Clear Opening 2000 mm In Width X 2400 mm Height
• Motor Make – DRUNKEN (Germany) - 24 v DC Brush Less Motor Heavy Duty 100 W (Noise Less)
• Control System: - Advance Self Learning Controller System. Compatible For Biometric & Electromagnetic Locking. Controller Compatible To Be Operational By Motion Sensors, Push Button, Biometric, Remote, Loop Detector. Required Safety Sensing Available. • Opening Closing speed: - Opening & Closing Speed Adjustable As Per Your Requirement
• Power supply: - Single Phase Power Supply Required – Can Operate On UPS & Invertor. Requires 24v DC Out Put To Run. Transformer Inbuilt. Very Less Power Consumption. Easy Operation Manuel In Case Of Power Failure.
• Sensors: - Motion Sensors – Qty. 02 No. Included (One From Out Side & Other From Inside). Range 3 Meter In Front. Motion Detection Can Be Adjustable As Per Requirement From 1.5 Feet’s To 03 Meters.
• Safety: - Safety Sensors Included
• Weight Capacity: - For Double Panels 100 Kg + 100 Kg Capacity & For Single Panel 150 Kg Capacity
Accessories Included: -
• Motion Sensor 2 No • Safety Sensor (One Set) • 12 mm Thick Glass Panel Holding Bracket 4 No.
• Moving Frame Panel Guiding Floor Bracket 2 No • Moving Frame- Less Guiding Floor Bracket 2 No
Includes Aluminium Track, Brush Less Motor, Intelligent Micro Controller, Timing Belt & Operator Cover.
