Barrier width of up to 3.5 m
Opening and closing times of minimum 1.3 s
Modular expandable control system
Limited approval for use with movement of persons
Technical data Access Pro
Barrier width Max. 3,5 m
Opening/closing time 1,3 s
Power consumption Max. 95 W
Drive technology MHTM™
Voltage 85-264 VAC, 50/60 Hz
Duty cycle 100%
Housing dimensions (L x W x H) 315 x 360 x 915 mm
Enclosure rating IP 54
Temperature range -30 to +55 °C
Weight 40 kg
Standard colours RAL 2000, 9006, 9007
VarioBoom barrier arm Standard
Control system MGC Pro
Integrated 2-channel detector for induction loops Standard
Modular expansion of control system Freely expandable
Variable I/O assignment Standard
No. of digital inputs 8
No. of relays/digital outputs 6/4
Input for safety light barrier with test Standard
Selectable closing speed Standard
Selectable opening speed Standard
